easyERF

NEW: The Intelligent Damper: easyERF

Electronic adjustable dampers according to the electrorheological technology

The Bansbach easyERF® dampers are extremely quick and efficient dampers with a broad application field.  Its innovation potential is the electronically adjustable damping intensity and the reaction time within milliseconds. Advantages of the damper include no wear and tear, maintenance-free, and high reliability.


Continuously Variable
A complete characteristic damper field is available.

Digital Control
By adapting the electrical input signal, the damping can be adjusted, either with PWM-standard or with 0 – 4 V analog signal.  SPS is possible; supply 24 V DC.

Response Characteristics
The required damper force can be realized with a reaction time of only a few milliseconds.

Noiceless and Maintenance-Free
No "laminar flow noises”, no "whistling noises”, & no moveable valve parts.

Energy-Efficient
Low consumption- High Efficiency







kennfeld1 e

The technology:

In the electrical field, the electrorheological fluid changes its consistency from thick to thin within milliseconds. According to the ERF-technology, the dampers adapt very quickly to changing system requirements, using as little energy as possible.

An electrical signal determines the damper forces which can thus be optimally adapted to operating excitation forces.

The damping force can consequently be adjusted within the characteristic field - quick, at any time, noiceless - and only by the use of a simple electronic interface.
